TEXAS INSTRUMENTS  MSP-EXP430G2  Integrated USB-powered Flash Emulation Tool, MSP430G2XX, Launchpad, 14/20 Pin DIP Socket, LED's

Technical Data Sheet (809.88KB) EN See all Technical Docs

Image is for illustrative purposes only. Please refer to product description.


Product Overview

MSP-EXP430G2 Launch Pad is easy-to-use Flash programmer and debugging tool for the MSP430G2xx Value Line microcontrollers. It features everything users need to start developing on an MSP430 microcontroller device. It has on-board emulation for programming and debugging and features a 14/20 pin DIP socket, on-board buttons and LEDs & Booster Pack-compatible pinouts that support a wide range of plug-in modules for added functionality.
  • Enables development on any MSP430 Value Line device with 14- or 20 pin DIP (N) packages
  • LaunchPad's integrated emulator interface connects Flash based MSP430 Value Line devices to a PC
  • Includes one mini USB cable to interface with a PC.
  • Included MSP430G2xx devices feature preloaded sample programs.
  • Free downloadable versions of IAR Kick-start and Code Composer Studio Version 5
  • 2 programmable LEDs, 1 power LED, 1 programmable button, 1 reset button
  • Built-in Flash emulation for debugging and programming
  • 10pin PCB connector
  • RoHS compliant

Product Information

Silicon Manufacturer:
Texas Instruments
Core Architecture:
Core Sub-Architecture:
Silicon Core Number:
Silicon Family Name:
No. of Bits:
Kit Contents:
LaunchPad Emulator, Mini USB-B Cable, Quick Start Guide
Product Range:
Kit Features:
Built-in Flash Emulation for Debugging and Programming, 14/20-pin DIP (N) Socket
Integrated USB-powered Flash Emulation Tool
No SVHC (15-Jun-2015)

Find similar products  grouped by common attribute


  • Power Management;
  • Sensing & Instrumentation;
  • Embedded Design & Development


MSP430G2553IN20 Flash device (preloaded with sample program10 pin PCB Connector (2 male/2 female) 32KHz crystal, Launch Pad Development board (MSP-EXP430G2), Launch Pad sticker, Mini USB cable, Quick Start Guide

Legislation and Environmental

Country of Origin:
United States

Country in which last significant manufacturing process was carried out

Tariff No:
Weight (kg):
