9-215464-0
Pin Header, Board-to-Board, 1.27 mm, 2 Rows, 20 Contacts, Through Hole Straight, Micro-MaTch
500 more incoming. You can reserve stock now
| Quantity | Price |
|---|---|
| 1+ | RM15.150 |
| 10+ | RM12.490 |
| 100+ | RM10.320 |
| 250+ | RM9.550 |
| 500+ | RM8.720 |
| 1000+ | RM8.250 |
Product Information
Product Overview
The 9-215464-0 is a 20-way 2-row Male-on-Board Ribbon Cable Plug with tin over nickel plated copper alloy contacts and tin over nickel plated solder tail. This Micro-MaTch series connector comes with red polyester GF housing and through hole termination. The Micro-MaTch contact helps prevent fretting corrosion, the traditional failure mode in tin-plated connections. Relative movements caused by vibrations/thermal expansion between male and female contacts are absorbed by an additional positioning spring in the female part. By preventing movements on the contact spot, a gas tight connection can make the Micro-MaTch contact spring system fretting corrosion resistant.
- UL94V-0 Flammability rating
- 1.5A Current rating
- 1000MΩ Insulation resistance
- 100VAC Voltage rating
- -40 to +105°C Operating temperature range
Applications
Industrial
Technical Specifications
Board-to-Board
2Rows
Through Hole Straight
Shrouded
Tin Plated Contacts
No SVHC (21-Jan-2025)
1.27mm
20Contacts
Micro-MaTch
Phosphor Bronze
PCB Header
Alternatives for 9-215464-0
1 Product Found
Associated Products
7 Products Found
Legislation and Environmental
Country in which last significant manufacturing process was carried outCountry of Origin:Germany
