element14's DIP (Dual In-line Package) and SIP (Single In-line Package) switches provide a versatile solution for configuring electronic circuits and systems. These compact switches are ideal for settings where numerous configuration options need to be set manually.

DIP switches allow for binary control of settings such as address assignment or operating modes in embedded systems. SIP switches, often used in high-density applications, provide the same functionality in a single row of contacts.

Applications:

Embedded Systems: Configuring microcontrollers or other programmable devices.
Communication Equipment: Adjusting frequencies or modes in radio and network devices.
Consumer Electronics: Customizing settings in devices like printers and gaming consoles.

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price	No. of Circuits	No. of Poles	Switch Actuator Style	No. of Switch Positions	Switch Mounting	Contact Configuration	Switching Voltage	Contact Voltage DC Max	Output Code	Pitch Spacing	Switching Current	Contact Current DC Max	Illumination	Switch Construction	Product Range	Switch Type	Actuator Level

ADF0604HL	2749882 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch 6 Circuits Through Hole SPST 24 V 100 mA	Each	1+RM5.980 10+RM5.800 25+RM5.650	6Circuits	-	-	-	Through Hole	SPST	-	24V	-	-	-	100mA	-	-	ADF Series	DIP	-
EDS02SGNNTR04Q	2792713 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch Raised Type 2 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM8.540 10+RM7.860 25+RM7.460 50+RM7.170 100+RM6.860	2Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	EDS Series	DIP Unsealed	-
76SB04ST	9479007 Data Sheet RoHS	GRAYHILL DIP / SIP Switch 4 Circuits Rocker Through Hole SPST 30 V 150 mA	Each	1+RM10.200 10+RM10.090	4Circuits	-	Rocker	-	Through Hole	SPST	-	30V	-	-	-	150mA	-	-	76 Series	DIP Sealed	-
EDS06SGRNTU04Q	2792689 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch Recessed Type 6 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM9.890 10+RM9.620 25+RM8.800 100+RM7.700 250+RM7.030 More Pricing...	6Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	EDS Series	DIP Unsealed	-
EDS10SNRNTR04Q	2792739 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch Recessed Type 10 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM15.170 10+RM13.350 25+RM12.630 50+RM12.140 100+RM11.650	10Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	EDS Series	DIP Unsealed	-
EDSP10SGLFNTR04	2792774 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch Long Type 10 Circuits Piano Key Surface Mount SPST 24 V 25 mA	Each	1+RM20.030 5+RM18.970 10+RM17.750 20+RM17.200 50+RM16.640	10Circuits	-	Piano Key	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	EDSP Series	DIP Unsealed	-
EDS10SNRSTU04Q	2792710 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch Recessed Type 10 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM13.400 10+RM12.590 25+RM12.360 50+RM12.120 100+RM11.880	10Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	EDS Series	DIP Sealed	-
EDS04SNNNTR04Q	2792723 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch Raised Type 4 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM14.260 10+RM12.090 25+RM11.240 50+RM10.670 100+RM10.090	4Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	EDS Series	DIP Unsealed	-
MCNDP-09V	2864296 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 9 Circuits Piano Key Through Hole SPST-NO 24 V 25 mA	Each	1+RM6.940 12+RM5.800 100+RM5.340 500+RM5.060	-	-	-	-	-	-	-	-	-	-	-	-	-	-	MCNDP-xxV	-	-
MCEMR-04-T	1524007 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 4 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM5.680 15+RM4.750 100+RM4.350 500+RM4.130 1000+RM3.950	4Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	MCEMR	DIP Sealed	-
SIP-06T	9471960 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 6 Circuits Slide Through Hole SPST 50 V 10 mA	Each	1+RM10.980 12+RM9.430 100+RM8.710 500+RM8.350 1000+RM8.050	6Circuits	-	Slide	-	Through Hole	SPST	-	50V	-	-	-	10mA	-	-	SIP	SIP	-
ADE0804	1123941 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch 8 Circuits Slide Through Hole SPST 24 VDC 100 mA	Each	1+RM5.180 10+RM5.060 25+RM4.960 50+RM4.860 100+RM4.760	8Circuits	-	Slide	-	Through Hole	SPST	-	24V	-	-	-	100mA	-	-	ADE Series	DIP Unsealed	-
MCDM(R)-04-T	9472037 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 4 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM4.500 15+RM3.760 100+RM3.450 500+RM3.270 1000+RM3.120	4Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	MCDM	DIP Sealed	-
ADE0404	1123938 Data Sheet RoHS	TE CONNECTIVITY - ALCOSWITCH DIP / SIP Switch 4 Circuits Slide Through Hole SPST 24 VDC 100 mA	Each	1+RM5.440 10+RM4.660 25+RM3.820 50+RM3.750 100+RM3.670	4Circuits	-	Slide	-	Through Hole	SPST	-	24V	-	-	-	100mA	-	-	ADE Series	DIP Unsealed	-
MCDM(R)-08-T	9472053 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 8 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM6.030 15+RM5.590 100+RM5.290 500+RM4.000 1000+RM3.790	8Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	DM	DIP Sealed	-
MCEMR-03-T	1524006 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 3 Circuits Slide Surface Mount SPST 24 V 25 mA	Each	1+RM5.430 10+RM4.610 25+RM4.420 50+RM3.810 100+RM3.640 More Pricing...	3Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	MCEMR	DIP Sealed	-
MCNDI-04S	9472169 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 4 Circuits Slide Through Hole SPST 24 V 25 mA	Each	1+RM4.670 10+RM4.100 25+RM3.730 50+RM3.500 100+RM3.360	4Circuits	-	Slide	-	Through Hole	SPST	-	24V	-	-	-	25mA	-	-	MCNDI	DIP Unsealed	-
MCDHN-08F-T-V	1605481 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 8 Circuits Flush Slide Surface Mount SPST 24 V 25 mA	Each (Supplied on Cut Tape) Cut Tape	1+RM10.780 12+RM9.280 100+RM8.630 500+RM8.200 1000+RM7.790	8Circuits	-	Flush Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	MCDHN	DIP Sealed	-
MCTIMR-08	1522015 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 8 Circuits Slide Surface Mount SPDT 24 V 25 mA	Each	1+RM7.830 12+RM6.520 100+RM6.010 500+RM5.730 1000+RM5.480	8Circuits	-	Slide	-	Surface Mount	SPDT	-	24V	-	-	-	25mA	-	-	Tri-State	DIP	-
TDA04H0SB1	2320112 Data Sheet RoHS	C&K COMPONENTS DIP / SIP Switch 4 Circuits Flush Slide Surface Mount SPST 24 V 25 mA	Each	1+RM14.250 10+RM12.140 25+RM9.550 50+RM9.340 100+RM9.120	4Circuits	-	-	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	TDA Series	DIP Sealed	-
MCDHN-08F-V	1605476 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 8 Circuits Slide Surface Mount SPST 24 V 25 mA	Each (Supplied on Cut Tape) Cut Tape	1+RM11.080 12+RM9.530 100+RM8.880 500+RM8.450 1000+RM8.030	8Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	MCDHN	DIP Unsealed	-
MCEPI-04	1522018 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 4 Circuits Piano Key Through Hole SPST 24 V 25 mA	Each	1+RM8.770 10+RM7.520 25+RM7.090 50+RM6.680 100+RM6.560	4Circuits	-	Piano Key	-	Through Hole	SPST	-	24V	-	-	-	25mA	-	-	MCEP	DIP	-
MCDHN-04F-T-V	1605479 Data Sheet RoHS	MULTICOMP PRO DIP Switch Slide Actuator 4 Circuits Half Pitch SPST 24 VDC 25 mA SMD	Each (Supplied on Cut Tape) Cut Tape	1+RM10.160 12+RM8.720 100+RM8.130 500+RM7.700 1000+RM7.340	4Circuits	-	Flush Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	MCDHN	DIP Sealed	-
MCDHN-02F-V	1605473 Data Sheet RoHS	MULTICOMP PRO DIP Switch Slide Actuator 2 Circuits Half Pitch SPST 24 VDC 25 mA SMD	Each (Supplied on Cut Tape) Cut Tape	1+RM9.910 12+RM8.530 100+RM7.930 500+RM7.520 1000+RM7.210	2Circuits	-	Slide	-	Surface Mount	SPST	-	24V	-	-	-	25mA	-	-	MCDHN	DIP Unsealed	-
MCNDS-06V	2864300 Data Sheet RoHS	MULTICOMP PRO DIP / SIP Switch 6 Circuits Slide Through Hole SPST-NO 24 V 25 mA	Each	1+RM5.140 15+RM4.290 100+RM3.940 500+RM3.740 1000+RM3.580	6Circuits	-	Slide	-	Through Hole	SPST-NO	-	24V	-	-	-	25mA	-	-	MCNDS-xxV	DIP	-
