8-188275-6
PCB Receptacle, Board-to-Board, 1.27 mm, 1 Rows, 16 Contacts, Surface Mount Straight, Micro-MaTch

| Manufacturer | TE CONNECTIVITY - AMP |
|---|---|
| Manufacturer Part No | 8-188275-6Copy |
| Manufacturer Standard Lead Time | 24 weeks |
| Order Code | Full Reel2399721 Cut Tape3784770 |
| Product Range | Micro-MaTch |
| Your Part Number | |
| Technical Datasheet |
Need more?
| Packaging Type | Quantity | Unit Price: | Total |
|---|---|---|---|
| Cut Tape | 1 | RM17.500 | RM17.50 |
| Total Price | RM17.50 | ||
| Quantity | Price |
|---|---|
| 1+ | RM17.500 |
| 22+ | RM14.990 |
| 67+ | RM13.920 |
| 180+ | RM12.850 |
| 450+ | RM12.600 |
| Quantity | Price |
|---|---|
| 900+ | RM10.870 |
| 2700+ | RM10.120 |
Product Information
| Manufacturer | TE CONNECTIVITY - AMP |
|---|---|
| Manufacturer Part No | 8-188275-6Copy |
| Manufacturer Standard Lead Time | 24 weeks |
| Order Code | Full Reel2399721 Cut Tape3784770 |
| Product Range | Micro-MaTch |
| Technical Datasheet | |
| Connector Systems | Board-to-Board |
| Pitch Spacing | 1.27mm |
| No. of Rows | 1Rows |
| No. of Contacts | 16Contacts |
| Connector Mounting | Surface Mount Straight |
| Product Range | Micro-MaTch |
| Contact Material | Phosphor Bronze |
| Contact Plating | Tin Plated Contacts |
| Contact Termination Type | Surface Mount Straight |
| SVHC | No SVHC (04-Feb-2026) |
Product Overview
The 8-188275-6 is a 16-way 1-row Female-on-board Connector with vertical PCB mounting orientation, surface mount device, low profile, tin plating over nickel solder tail, tin plating over nickel phosphor bronze contact. This SMD connector version is designed for standard reflow and infrared solder processes (FULL SMD). Polarization is accomplished by the housing, there for no polarization holes in the PC board are required. The contact is designed with an additional spring to compensate for differences in thermal expansion between housing and PCB. Due to this feature, tension on solder joints is prevented.
- UL94V-0 Flammability rating
- Shrouded type
- 1000MΩ Insulation resistance
- 100VDC Operating voltage
- Dual beam contact
- Polarization mating alignment
Applications
Industrial
Technical Specifications
| Connector Systems | Board-to-Board |
|---|---|
| No. of Rows | 1Rows |
| Connector Mounting | Surface Mount Straight |
| Contact Material | Phosphor Bronze |
| Contact Termination Type | Surface Mount Straight |
| Pitch Spacing | 1.27mm |
|---|---|
| No. of Contacts | 16Contacts |
| Product Range | Micro-MaTch |
| Contact Plating | Tin Plated Contacts |
| SVHC | No SVHC (04-Feb-2026) |
Alternatives for 8-188275-6
1 Product Found
Associated Products
7 Products Found
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | Germany Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85366930 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | No SVHC (04-Feb-2026) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .001183 |
