ANALOG DEVICES HMC4069LP4E

Frequency Synthesizer, Integer-N, 4.75 to 5.25 V, 2.9 GHz, -40 to 85 °C, QFN-EP-24

ANALOG DEVICES HMC4069LP4E
×

Image is for illustrative purposes only. Please refer to product description.

Manufacturer Part No:
HMC4069LP4E
Order Code:
4030757
  • Enter your custom part number in the textbox above

Part Number Saved

Part Number Saved

Technical Datasheet:
HMC4069LP4E   Datasheet
ECAD / MCAD
Supply Frame Models Link
See all Technical Docs

Product Overview

HMC4069LP4E is a integer-N synthesizer. It incorporates a 10MHz to 1300MHz digital phase-frequency detector with a 10MHz to 2900MHz 5-bit frequency counter. It is intended for use in low phase noise synthesizer applications. The combination of high frequency of operation along with its ultra low phase noise floor make possible synthesizers with wide loop bandwidth and low N resulting in fast switching and very low phase noise. When used in conjunction with a differential loop amplifier, this device generates output voltages that can be used to phase lock a VCO to a reference oscillator. It is used in applications such as point-to-point radios, satellite communication systems, military applications, sonet clock generation etc.
  • Ultra low SSB phase noise floor is -151dBc/Hz typical at (10KHz offset at 100MHz)
  • Integrated output resistors
  • Improved input sensitivity
  • Lock detect and invert functionality
  • Input power range is 5dBm typical at (TA = +25° C, Vcc = 5V)
  • Supply voltage is 5V typical at (TA = +25° C, Vcc = 5V)
  • Supply current is 295mA typical at (TA = +25° C, Vcc = 5V)
  • Operating temperature is -40°C to +85°C
  • Package style is 24-pin SMT

Product Information
