Image is for illustrative purposes only. Please refer to product description.

| Manufacturer | FTDI |
|---|---|
| Manufacturer Part No | DB9-USB-D3-FCopy |
| Manufacturer Standard Lead Time | 44 weeks |
| Order Code | 2419925 |
| Your Part Number | |
| Technical Datasheet |
1 In Stock
50 more incoming. You can reserve stock now
1 Delivery in 3-4 Business Days(UK stock)
| Quantity | Price |
|---|---|
| 1+ | RM115.960 |
| 5+ | RM114.000 |
| 10+ | RM112.040 |
| 50+ | RM110.580 |
| 100+ | RM109.380 |
| 250+ | RM107.200 |
Price for:Each
Minimum: 1
Multiple: 1
RM115.96
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
| Manufacturer | FTDI |
|---|---|
| Manufacturer Part No | DB9-USB-D3-FCopy |
| Manufacturer Standard Lead Time | 44 weeks |
| Order Code | 2419925 |
| Technical Datasheet | |
| Bridge Type | USB to UART |
| Module Interface | UART, USB |
| Supported Devices | FT232R |
| Supply Voltage Min | - |
| Supply Voltage Max | 3.3V |
| Product Range | - |
| SVHC | No SVHC (04-Feb-2026) |
Product Overview
DB9-USB-D3-F is a USB to 3.3V TTL UART serial adapter with embedded electronics to retrofit a DB9 female connector. This is an USB to 1-port 3.3V level UART module that can replace 3.3V level UART DB9 female connector.
- USB to serial UART converter packaged in DB9 female connector ideal for bridging serial ports to USB
- Modules feature a USB2.0 Mini-B type connector
- Designed to fit a standard 9-pin DB9 based RS232 connector pin out
- Internal electronics to carry out full conversion between 3V3 UART and USB
- Module supplied complete with FTDI royalty free drivers
- Microsoft WHQL certified drivers for Windows operating systems
- Drivers also available for Linux and Mac OS
- VCP (Virtual COM port) and D2XX API based drivers available
- CE, FCC and UKCA approved
- 3MBaud data rates, 12Mbps USB speed, Mini B USB connector, female DB9 pin out I/O connector
Technical Specifications
| Bridge Type | USB to UART |
|---|---|
| Supported Devices | FT232R |
| Supply Voltage Max | 3.3V |
| SVHC | No SVHC (04-Feb-2026) |
| Module Interface | UART, USB |
|---|---|
| Supply Voltage Min | - |
| Product Range | - |
Technical Docs (1)
Associated Products
2 Products Found
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | China Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85366990 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | No SVHC (04-Feb-2026) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .005 |
