RCR-433-MPR
RF MOD, RX, ASK / OOK, SUPER-REGEN
Image is for illustrative purposes only. Please refer to product description.
| Manufacturer | RADIOTRONIX |
|---|---|
| Manufacturer Part No | RCR-433-MPRCopy |
| Order Code | 1565152 |
| Product Range | TUK SGACK902S Keystone Coupler |
| Your Part Number | |
| Technical Datasheet |
No Longer Stocked
Product Information
| Manufacturer | RADIOTRONIX |
|---|---|
| Manufacturer Part No | RCR-433-MPRCopy |
| Order Code | 1565152 |
| Product Range | TUK SGACK902S Keystone Coupler |
| Technical Datasheet | |
| RF Modulation | ASK, OOK |
| Data Rate Max | 4.8Kbps |
| Frequency | 433.92MHz |
| Sensitivity dBm | -105dBm |
| Supply Voltage Min | 4.75V |
| Supply Voltage Max | 5.25V |
| Supply Current | 4mA |
| Supported Devices - RF Receivers | - |
| RF Receiver Applications | - |
| Product Range | TUK SGACK902S Keystone Coupler |
| SVHC | No SVHC (08-Jul-2021) |
Product Overview
The RCR-433 MPR is a miniature receiver module that receives On-off keyed (OOK) modulation signal and demodulated to digital signal for the next decoder stage. Local Oscillator is made of L/C structure. RCR-433-MPR has excellent performance and simple to use. RCR-433-MPR is designed specifically for unlicensed remote control and wireless security receiver operating at 433MHz in USA under FCC Part 15 regulation.
- The module's frequency is from UHF (ASK) 280~433.92 MHz
- High sensitivity passive design
- 4800 B/S baseboard data rate
- simple to apply with low external parts count
- Low supply voltage
- ASK data shaping comparator Included
Applications
Building Automation, Sensing & Instrumentation, Lighting, Security, Medical, Industrial, Wireless
Technical Specifications
| RF Modulation | ASK, OOK |
|---|---|
| Frequency | 433.92MHz |
| Supply Voltage Min | 4.75V |
| Supply Current | 4mA |
| RF Receiver Applications | - |
| SVHC | No SVHC (08-Jul-2021) |
| Data Rate Max | 4.8Kbps |
|---|---|
| Sensitivity dBm | -105dBm |
| Supply Voltage Max | 5.25V |
| Supported Devices - RF Receivers | - |
| Product Range | TUK SGACK902S Keystone Coupler |
Technical Docs (1)
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | United States Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85235290 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | To be advised |
| SVHC: | No SVHC (08-Jul-2021) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .0024 |
